Simrad A2004 – Autopilot Pack with Control Display

Commercial workboat captains execute precision thruster and rudder maneuvers through this Simrad A2004 autopilot controller, which displays navigation data across an optically bonded 4.1-inch color screen inside an IPX7 front housing at 2.2W.

Bonded 4.1-inch color LCD prevents internal moisture
Rotary dial provides smooth commercial rudder control
Dual NMEA 0183 ports connect gyrocompass inputs
Integrates thruster control for harbor docking
Die-cast aluminum chassis withstands bridge demands

$3,293.00

Availability In stock and available to order

Buy Now

Bulk order support Request for Quotation

Compare Ask a question

Category: Marine Autopilots Brand: Simrad SKU: 000-13900-001

Free standard shipping to eligible destinationsSecure checkout

The Simrad A2004 Autopilot Pack with Control Display is a professional autopilot solution built around the A2004 color control display and a compatible Simrad autopilot computer. It is intended for larger recreational, commercial, and workboat installations using properly matched hydraulic pumps, solenoid steering, mechanical drives, or integrated thruster-control arrangements. The A2004 is a helm control interface and does not directly power a steering drive.

The system supports 12V or 24V installations and uses NMEA 2000 Micro-C networking with NMEA 0183 connectivity through the selected course computer. It can work with compatible Precision-9, GPS compass, or other approved heading sources, plus physical or networked rudder feedback where required. Confirm the exact pack contents because controller-only and complete-pack versions can differ in their included course computer, feedback sensor, and compass.

System Integration

The A2004 controller is part of a complete autopilot architecture, not a standalone steering controller. Drive capacity depends on the selected AC70, AC80, NAC-3, or other compatible Simrad course computer. Match the computer to the actual pump, motor, linear drive, rotary drive, solenoid, or thruster current and duty-cycle requirements.

For commercial and high-load installations, verify steering-gear compatibility, redundancy requirements, feedback sensor type, heading-source accuracy, network design, and applicable regulatory requirements. The A2004 display can show and control system functions, but safe operation depends on the correctly installed complete autopilot system.

Before Ordering

Confirm the exact A2004 pack contents, selected compatible course computer, steering drive type, drive current and duty cycle, heading sensor, rudder-feedback method, 12V or 24V supply, NMEA 2000 backbone, NMEA 0183 requirements, helm mounting space, protected computer location, circuit protection, and complete autopilot-system requirements before purchase.

Product Specifications
