SIONYX Nightwave Digital Camera – Black
Matching black radar arches on offshore center consoles, a SIONYX NCV-1000-BLK digital camera captures 720p color night vision across a 44-degree field of view, streaming analog BNC video down to -32°C at 1.92 lbs.
- Black-silicon CMOS captures true night color
- 44-degree field of view widens horizon
- IP67 submersible enclosure prevents water ingress
- Operates reliably from -32°C to 55°C
$1,713.03
Availability
In stock and available to order
Bulk order support
Request for Quotation
Free standard shipping to eligible destinationsSecure checkout
Maintain a clean black camera installation while adding ultra-low-light video to the helm with the SIONYX Nightwave Digital Camera in Black. Its Black Silicon CMOS sensor and 44° fixed field of view help produce a color image under starlight conditions, making it useful for dock approaches, nighttime cruising, and monitoring the water ahead without adding a large pan-and-tilt assembly. Need a permanent low-light camera that connects to an existing analog display input? The Nightwave provides 720p video over BNC, 12V DC power, and IP67 protection in a compact black housing.
Integration
The Nightwave requires a compatible analog-video display or an appropriate BNC video interface. It is not an Ethernet IP camera, NMEA 2000 device, chartplotter, radar, or GPS unit. Confirm whether the intended display accepts the required analog video signal and identify any needed BNC, RCA, or display-specific adapters.
Its low-light imaging performance depends on available starlight or moonlight, glare, rain, haze, spray, target contrast, lens cleanliness, and camera placement. It is an additional observation tool—not a replacement for navigation lights, radar, charts, visual lookout, or safe operating procedures.
Before Ordering
Confirm analog-video compatibility, required connectors or adapters, black-housing preference, 12V power availability, camera viewing direction, mounting location, and cable routing before ordering.
Product Specifications
SIONYX Nightwave Digital Camera - Black
| Brand | SIONYX |
|---|---|
| Full Model SKU / Code | NCV-1000-BLK |
| Device Type | Ultra Low-Light Digital Marine Night Vision Camera (Black Housing) |
| Display Size | N/A (Connects to Compatible MFD / Monitor) |
| Display Resolution | 1280 x 720 pixels (720p HD Video Output) |
| Display Type | N/A |
| GPS Receiver / GNSS | N/A |
| Receiver Update Rate | N/A |
| Position Accuracy | N/A |
| Preloaded Maps / Charts | N/A |
| Chart Compatibility | N/A |
| Waypoints / Routes / Track Log | N/A |
| NMEA Network Compatibility | Analog Video Output (BNC) / Wi-Fi Streaming |
| Wireless Connectivity | Wi-Fi & Bluetooth (via SIONYX App Integration) |
| Sonar Specifications | Patented Black Silicon 1/2.1" CMOS Sensor (44° Field of View, Starlight Night Vision Capability) |
| Waterproof Rating | IP67 Submersible Enclosure |
| Operating Voltage Range | 12 V DC |
| Power Consumption | Max 5.0 W |
| Operating Temperature | -32°C to 55°C (-25°F to 131°F) |
| Dimensions (ø x L) | 127 x 152 mm (5.0 x 6.0 in) |
| Dry Weight | 0.87 kg (1.92 lbs) |
| Mounting Options | Permanent Deck Mount / Ball-Joint Bracket Mount |
