Mastervolt ChargeMaster Plus 12V / 75A – 3 Banks CZone Marine Battery Charger – 44310755
Built to SAE J1171 ignition protection standards, the 7 kg Mastervolt ChargeMaster Plus 12/75-3 multi bank marine charger charges three 12V banks with 75A total output on cruising yachts.
- Three outputs handle mixed chemistries.
- Ignition protected design enhances safety.
- Included sensor adjusts charging voltage.
- Full electronic protections stop overloads.
- Hardware enclosure weighs 7 kg.
$981.36
Availability
In stock and available to order
Bulk order support
Request for Quotation
Free standard shipping to eligible destinationsSecure checkout
Built around three combined 12V banks, theMastervolt ChargeMaster Plus 12/75-3 Marine Battery Chargersupplies 75 amps through a universal 80V to 275V AC input range. It supports listed LiFePO4, AGM, gel, and flooded chemistries with 3-Stage+ smart charging, 14.25V absorption, and 13.25V float values.
MasterBus, CZone, and NMEA 2000 provide listed communication options for compatible systems. The included sensor supports temperature compensation, while 92 percent efficiency, IP23 protection, SAE J1171 ignition protection, full DC and AC protection, and intelligent fan control are documented.
Warranty and Support
Warranty information is not included in the listed product data. Review the manufacturer documentation for product details, setup, and warranty coverage.
Before Ordering the Mastervolt ChargeMaster Plus 12/75-3 Marine Battery Charger
Before ordering, verify that your 12V system uses up to three combined banks, needs up to 75 amps, and accepts 80V to 275V AC input. Review the listed chemistry profiles, network interfaces, IP23 protection, sensor inclusion, installation space, and warranty availability. You should confirm compatibility with your battery manufacturer and vessel electrical system before purchase.
Product Specifications
Mastervolt ChargeMaster Plus 12/75-3
| Brand | Mastervolt |
|---|---|
| SKU | 44310755 |
| Output Current | 75 Amps |
| Isolated Banks | 3 Banks (Combined) |
| DC Voltage | 12V DC |
| Input Voltage | 80-275V AC (Universal) |
| Battery Types | LiFePO4, AGM, Gel, Flooded |
| Algorithm | 3-Stage+ Smart Charging |
| Absorption/Float | 14.25V / 13.25V |
| Efficiency | 92% |
| IP Rating | IP23 |
| Ignition Protected | Yes (SAE J1171) |
| Communication | MasterBus, CZone, NMEA 2000 |
| Temp Compensation | Sensor Included |
| Safety Protections | Full DC/AC Protection |
| Cooling | Vario-Speed Intelligent Fan |
| Dimensions | 384 x 226 x 143 mm (15.1x8.9x5.6") |
| Weight | 7 kg (15.4 lbs) |
| Certifications | CE, ABYC, UL1236, CSA |
| Application | Mid-High Capacity 12V Systems, CZone Integration |
