Webasto C27 M C-Series 27000 BTU Marine Chiller

The Webasto C27 M provides 27,000 BTU marine chiller capacity for centralized cooling across compact and medium vessel interior zones.

27,000 BTU capacity supports medium zones.
C27 M identifies the configuration.
Marine chiller serves centralized cooling.
Output suits multiple interior spaces.
System requires compatible water distribution.

$2,402.40

Availability In stock and available to order

Buy Now

Bulk order support Request for Quotation

Compare Ask a question

Category: Marine Air Conditioners Brand: Webasto SKU: WBCL1205003D

Free standard shipping to eligible destinationsSecure checkout

Boats with three independent cabins needing a properly sized central chiller without excess capacity find a good match in the Webasto C27, delivering 27,000 BTU/h from a compact 88 lb unit. This small central chiller three cabins system is positioned between Webasto’s smallest and mid-capacity C-Series options.

Interestingly, this unit’s locked rotor amperage (54A) matches the figures published for Webasto’s much larger C81 and C108 models — a detail that likely reflects a shared compressor platform used across several capacity tiers in the C-Series lineup, which is common practice for manufacturers standardizing on proven components.

Why Choose the Webasto C27

This unit carries Webasto’s standard 2-year warranty. Unlike several other listings in this lineup, this product page’s naming is internally consistent, which simplifies confirming you’re ordering the correct part number.

What to Know Before Installing

This chiller requires separately specified air handlers (Webasto’s A-Series) distributed to each independent zone
Ships via freight given the 88 lb weight; commercial delivery address required
Professional installation and electrical planning is strongly recommended

Product Specifications

Brand	Webasto Marine
Full Model SKU/Code	BlueCool C27 M (C-Series Mono)
Country of Origin	Germany
AC System Type	Central Single-Stage Chilled Water Marine Air Conditioning System
Cooling Capacity	27,000 BTU/h (7.9 kW / 2.25 Tons)
Heating Capacity	27,000 BTU/h (Reverse Cycle Heat Pump Mode)
Refrigerant Type	R-410A Pre-Charged Eco-Friendly Gas
Compressor Technology	High-Efficiency Hermetic Rotary Compressor
Operating Voltage / Frequency	230 Volts AC / 50 or 60 Hz Single Phase Base Rail
Full Load Amps / Running Current	Cooling Duty: 6.8 Amps / Heating Duty: 7.6 Amps at 230V Input Cycle
Locked Rotor Amps / Starting Current	32.0 Amps LRA Base Threshold
Recommended Circuit Breaker Rating	15 Amps Heavy-Duty Marine Breaker
Required Sea Water Flow Rate	350 GPH / 22.1 Liters per minute minimum loop
Sea Water Inlet/Outlet Size	5/8" (16mm) Inner Diameter Hose Barb Connections
Chilled Water Loop Connections	3/4" (19mm) Threaded Quick-Connect Internal Interface Ports
Condenser Coil Material	Corrosion-Resistant Cupronickel (CuNi 90/10) Coaxial Heat Exchanger Tube
Control Interface Connectivity	BlueCool MyTouch Digital Touch Controller & NMEA 2000 Data Bus Integration Capable
Dimensions (L x W x H)	48.5 cm x 35.0 cm x 39.5 cm / 19.1" x 13.8" x 15.6"
Dry Weight	41.0 kg / 90.4 lbs (Premium epoxy-coated structural safety frame tray assembly)
Application	Compact centralized water chilling for custom motor yachts, sportfishers, and coastal cruising vessels seeking low mechanical sound signatures in guest quarters (32-45 ft boat lengths)
