Octopus Type S Straight Shaft f/Mounting Behind the Dash f/Mechanical Drive Systems – Includes 90° Bezel Kit
Tight center console dashboards fit an Octopus Type S autopilot controller via an included 90-degree bezel, delivering 150 lbs of mechanical cable thrust from a 12V reversing gear motor across a 210mm depth at 8.6 lbs.
- 90-degree bezel fits compact dashboard helms
- 150-lb thrust actuates mechanical steering cables
- Reversing gear motor provides responsive steering
- 12V system draws 5A during cruising
- Quick-connect socket speeds cable helm installation
$492.80
Availability
In stock and available to order
Bulk order support
Request for Quotation
Free standard shipping to eligible destinationsSecure checkout
The Octopus Type S Straight Shaft Mechanical Drive with 90° Bezel Kit is a compact behind-dash mechanical autopilot drive for compatible standard push-pull steering cables. Its straight-shaft design is suited to helm consoles where an angled or tilt steering shaft is not required. The package includes a 90-degree bezel kit and mounting hardware for the stated flush-mount mechanical-drive configuration.
The 12V reversing gear motor delivers up to 150 lb of cable thrust, typically draws 3A to 5A, and can reach 12A under maximum load. It requires about 210 mm of behind-dash depth and weighs 3.9 kg, or 8.6 lb. This component is a steering drive only and requires a compatible autopilot computer, heading sensor, control interface, power system, and correctly installed mechanical steering cable.
Before Ordering
Confirm a compatible straight-shaft mechanical helm, standard push-pull steering cable, 210 mm behind-dash depth, required 90-degree bezel orientation, matching autopilot processor, 12V supply, 12A circuit capacity, dashboard structural support, cable bend radius, full manual steering operation, and complete autopilot-system components before purchase.
Product Specifications
Octopus Type S Straight Shaft f/Mounting Behind the Dash f/Mechanical Drive Systems - Includes 90° Bezel Kit
| Drive Type | Mechanical Rotary Straight Drive |
|---|---|
| Pump/Ram Capacity | Direct Shaft Mechanical Helm |
| Flow Rate / Speed | Constant Ratio Steering |
| Max Pressure | 150 lbs Maximum Cable Thrust |
| Cylinder Compatibility | Standard Mechanical Steering Cables |
| Operating Voltage | 12V DC System |
| Peak Current Draw | 12 Amps Maximum |
| Average Power Draw | 3A - 5A Typical Use |
| Motor Type | Integrated Reversing Gear Motor |
| Computer Compatibility | Universal (Simrad, Garmin, Raymarine) |
| Port Size / Thread | Standard Quick-Connect Cable Port |
| Drive Connection | Straight Steering Shaft Interface |
| Rotation/Stroke Direction | Reversible Rotary Cable Motion |
| Mounting Type | Behind-Dash Flush Mount |
| Housing Material | Reinforced Steel & Industrial ABS |
| Waterproof Rating | Splash-Protected Interior Housing |
| Operating Temperature | Standard Marine Environment Grade |
| Length (Overall) | 210 mm Drive Depth |
| Width/Diameter | Standard Steering Helm Frame |
| Weight | 3.9 kg (8.6 lbs) |
| Included Accessories | 90° Bezel Kit, Mounting Hardware |
| Key Mechanical Feature | Compact straight shaft for tight consoles |
